The GM4301TAD HMI offers a 5.7" LED backlit LCD Display. Display and Communication modules can be separated for quick mounting into a standard 22mm hole without the need to create a larger panel cutout. It offers a full graphics touch screen interface with a selection of serial or ethernet connectivity. This models are programmed with the versatile GP-Pro EX development software.
Unit of Measure
Specifications
Graphic Display Dot |
N/A 320 x 240 pixels (QVGA) |
Display Type and Size |
N/A TFT Color LCD (5.7 inch) |
Display Colors |
N/A 65,536 colors |
USB |
N/A 1 Type-A and 1 mini-B |
Serial |
N/A RS-232C/422/485 |
Ethernet |
N/A IEEE802.3i/ IEEE802.3u, 10BASE-T/100BASE-TX, Connector: Modular jack (RJ-45) x 1 |
Input Voltage |
N/A 24VDC (20.4 ->28.8) |
Power Consumption |
N/A <= 6.8W |
Ambient Operating Temp |
N/A 0 to 50 °C (32 to 122 °F) |
Certifications |
N/A CE, UL Listed Cl 1 Div 2, RoHS |
Clock Accuracy |
N/A Uses the clock of an external device |
PCMCIA |
N/A not_equipped |
CF Card |
N/A not_equipped |
Colors |
N/A 65536_colors |
I/O Control |
N/A not_equipped |
LT3000 CanOpen |
N/A not_supported |
Communications |
N/A Ethernet USB |
Screen Type |
N/A TFT Color LCD |
Handheld Configuration |
N/A No |
Display Type |
N/A TFT Color LCD |
Rated Input Voltage |
N/A DC 24V |
Power Supply |
N/A DC |
Address |
N/A Proface America, 1050 Highland Drive, Suite D, Ann Arbor, MI, 48108, 734-477-0600 |
Supported Software |
N/A GP-Pro EX |
Accessories
Accessories |
N/A
PFXEXEDLS40A, GP-Pro EX HMI Development Software (QUOTE) PFXGM4B01D, GP4000M Rear Module (QUOTE) PFXZCBDS61, 5.7" Screen Protection Sheet (QUOTE) PFXZGMCNDC1, DC Power Supply Connector (QUOTE) |
